Description
Technical Specifications
| Specification | Details |
|---|---|
| Product Type | DC High Voltage Break Down Tester |
| Number of Channels | 5 Channels |
| Channel Configuration | Individual control for Channel 1 to Channel 5 |
| Display & Control | Touchscreen HMI |
| Voltage Adjustment | Individual voltage adjustment for each channel |
| High Voltage Output | Dedicated HV output terminals for 5 channels |
| Channel Control | Individual HT ON/OFF control |
| Protection | Fuse and resettable fuse indication/protection |
| Interface | Digital touchscreen monitoring and control |
| Application | High-voltage breakdown and dielectric testing |
Product Description
The DC High Voltage 5 Channel Break Down Tester is a multi-channel high-voltage testing system designed for laboratory, quality control, production testing, and electrical insulation evaluation applications. The equipment provides five independent high-voltage test channels, allowing multiple test points or specimens to be handled through a centralized control panel.
The system is equipped with a touchscreen HMI for convenient operation, monitoring, and test management. Each channel incorporates an individual voltage adjustment control, HT ON/OFF indication, fuse protection, and dedicated high-voltage output connections. This channel-wise configuration provides flexibility when performing high-voltage breakdown and insulation-related tests.
The dedicated 5-channel HV output section provides separate connections for each test channel. Individual channel controls help the operator manage the testing sequence while the visual indicators provide clear status information during operation.
The robust panel-mounted construction is suitable for demanding electrical testing laboratories, cable and wire testing facilities, electrical component manufacturers, and quality assurance departments.
Key Features
- 5-channel DC high-voltage testing configuration
- Touchscreen HMI for operation and monitoring
- Individual voltage adjustment for each channel
- Separate HV output terminals for all five channels
- Individual HT ON/OFF controls and indicators
- Channel-wise fuse and resettable fuse protection
- Centralized control panel for convenient operation
- Suitable for laboratory and production-line testing
- Designed for DC high-voltage breakdown and insulation testing
Applications
The DC High Voltage 5 Channel Break Down Tester can be used for:
- Electrical insulation testing
- High-voltage breakdown testing
- Wire and cable testing
- Electrical component testing
- Quality control and production testing
- Laboratory dielectric testing
- Testing of insulation materials and assemblies.
Model
Model: DCHV2K5
