Specifications
-
Model: CS-630S
-
Attachment Length: 1 meter
-
Applicable Cable Size: 50 mm² to 630 mm² (sector-shaped)
-
Mounting Type: Clamps mounted on heavy-duty teakwood attachment
-
Wood Thickness: Approx. 20 mm
-
Testing Capability: Measures resistance of 1-meter cable length
-
Clamping Method: Tightening key included
-
Material: Premium teakwood with robust metal clamps
-
Application: Resistance testing, quality control, R&D labs
Clamping System CS-630S – Precision Clamp Setup for 1-Meter Cable Resistance Testing
The Clamping System CS-630S is a high-performance fixture designed for accurate resistance testing of sector-shaped cable samples ranging from 50 mm² to 630 mm². The system features robust clamps mounted on a 1-meter teakwood attachment, allowing precise measurement of the cable’s resistance over a fixed length.
The attachment is crafted from high-quality teakwood, offering excellent mechanical strength and insulation. With a thickness of approximately 20 mm, the wooden base provides a stable and vibration-free platform for secure cable clamping.
The integrated heavy-duty clamps ensure a firm grip on the sample, preventing movement during testing. A tightening key is included for easy and reliable compression of the cable ends, ensuring minimal contact resistance and consistent test results.
Ideal for cable manufacturers, R&D units, and quality-control laboratories, the CS-630S provides a robust, easy-to-use, and long-lasting solution for precise 1-meter cable resistance measurement.
